Detailed specifications
Type | SW-215 |
Size (mm) | 300*180*101 |
Size of the feeder (mm) | 215*160*19 |
Weight | About 6.2kg
|
Voltage | DC20-30V(Recommended 24V) |
Maximum current | 6A |
How it works | Move up, down, left, right, top left, bottom left, top right and bottom right, middle up and down, middle left and right, shake and flip, and vibrate directly to load |
Regularity | 10~131Hz |
Operating noise | <50dB |
Maximum load | 0.5kg |
Weight of a single flipped material | <15g |
Signal interaction | TCP/IP communication |
Input/Output Interface |
External dimensions
